JBL CSS-H30 Commercial Solutions Series 30W Paging Horn Traffic

533 د.إ

The Commercial Solutions Series CSS-H30 Paging Horn provides excellent voice range clarity for public address systems, announcement/paging, intercom, security, alarm and industrial applications. Designed for demanding environmental conditions, the CSS-H30 is highly weather-resistant (IP-65 rated) so it can be used in either indoor or outdoor applications. The wide coverage pattern allows the horn to cover a larger audience area than is the case with many paging horns.

SKU: CSS-H30 Categories: ,

Description

JBL CSS-H30  offers Excellent voice range clarity for announcements and paging.

Frequency Response  380 Hz – 6 kHz

Power Capacity 30 W (120 W peak), 100 hours

Maximum SPL 3.3′ (1.0 m): 123 dB continuous averaged (129 dB peak), 1 kHz to 6 kHz 127 dB continuous average (133 dB peak), 1.4 kHz, 30 W input, 8 Ω setting

Impedance 30 W / 70 V, NC / 100 V Tap: 167 Ω 15 W / 70 V, 30 W / 100 V Tap: 333 Ω 7.5 W / 70 V, 15 W / 100 V Tap: 667 Ω 3.8 W / 70 V, 7.5 W / 100 V Tap: 1333 Ω 1.9 W / 100 V, 3.8 W / 100 V Tap: 2666 Ω 8 Ω at 8 Ω direct setting

Dimensions Horn Only: 8.2 x 11.2 x 11.3″ (20.6 x 28.5 x 28.7 cm) With Mounting Bracket: 8.9 x 11.2 x 11.3″ (22.4 x 28.5 x 28.7 cm) (depth excludes cable exit)

High sensitivity delivers high sound levels with minimal power amplification.

Focused 50° horizontal by 70° vertical coverage for long-throw capability.

UL-registered 30-watt multi-tap transformer, with an 8-ohm direct bypass
