Dynacord CMS 600-3 8‑channel Compact Mixing System has Intuitive mixer section: with 8 input channels with 4 Mic/Line, 2 Mic/Stereo-Line, 2 Stereo-Line inputs
High-Quality FX processors, editable with 100 factory and 20 user presets
Professional 4×4 24-bit/96kHz USB interface, recording software and MIDI interface for FX control
Stereo EQ for the main mix
Large, contrast rich OLED display
Lightweight (5.8kg) super compact package
Dynacord CMS 600-3 8‑channel Compact Mixing System
4,800 د.إ
Description
Crosstalk: < Channel to Channel: < -80dB; Mute and Standby switch attenuation: > 100dB; Fader and FX/AUX/MON-Send attenuation: > 85dB;dB
Frequency Response (-3 dB) 15Hz to 70kHz
Power Requirement 100V to 240VAC, 50Hz to 60Hz
Power Consumption 35W
Height 4.31″ (109.6mm) Width 16.41″ (416.9mm) Depth 13.69″ (347.8mm)
Weight Net 12.79lbs (5.8kg)
Input Impedances MIC: 2㏀; CD In: 10㏀; All other inputs: > 15㏀;
Input Sensitivity MIC: -74dBu (155μV); LINE (Mono): -54dBu (1.55mV); LINE (Stereo): -34dBu (15.5mV); CD (Stereo): -34dBu (15.5mV);
Maximum SPL MIC inputs: +12dBu; Mono Line inputs: +31dBu; Stereo Line inputs: +30dBu; All other inputs: +22dBu; All other outputs: +22dBudB
MIC GAIN (Stereo) +10 to +60dB
MIDI Interface 5-pin DIN connector, In / Out
Operating Temperature Range +5 °C…+40 °C (40 °F…105 °F)
Output Impedances Phones: 47Ω; All other outputs: 75Ω (unbalanced), 150Ω (balanced)
Phantom Power 48VDC
Total Harmonic Distortion <0.005%
