Yale YDM3109 Digital Door Lock, PIN Code, RFID

1,503 د.إ

Yale YDM3109 mortice lock is a smart solution for residential & “light” commercial applications. 2 access solutions to open your door: RF Card key & PIN code. Innovative features, such as alarms, fake code or automatic locking, YDM3109 will provide comfort and will increase your feeling of security.

SKU: YDM3109 Categories: ,


Yale YDM3109 Digital Door Lock, PIN Code, RFID
Double credentials (PIN code & RF Card key)
Fake PIN code
Operation status notification
Mechanical key override
Missing key invalidation
Automatic locking
Anti-panic egress with safe handle
Alarm (break-in/damage)
Low battery alarm & emergency power with 9v battery
-Pin code (6-12 digits)
Proximity card: 4 (up to 40 users)
Mechanical key: 2
Center distance: 72mm
Backset: 60mm
Color: silver
Door thickness: 40-80mm
Dimensions: front body 27 (D) x 68.6 (W)x306.6 (H)mm; back body 37(D)x72.8 (W)x 306.6 (H)mm
Integration: available upon request-RF link
IP 55: water resistant

Compatible for both Left and Right side door opening
